AOOSTAR

MN68 / AM20 6800U 32GB

Name: AOOSTAR MN68 / AM20 6800U 32GB
Brand: AOOSTAR

CPU r7 6800U

GPU RDNA2 680M

Max RAM 32GB

Drives 3

From $280

Seller Amazon

The AOOSTAR MN68 / AM20 6800U 32GB is a mini PC powered by the AMD r7 6800U (Zen 3+ gen). It features 8 performance cores and 16 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA2 680M. Supports up to 32GB of RAM at 6400 MT/s. Storage capacity of up to 3 drives including 3 NVMe. Connectivity includes USB4 40Gbps. Networking features 2 Ethernet ports (up to 2.5G). Dimensions: 108 × 108 × 40mm (0.47L).

CPU & Performance

CPUr7 6800U

GenerationZen 3+

P-Cores8

Threads16

Single-core63

Multi-core30

Socket0

GPU

GPURDNA2 680M

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

RAM

Max RAM32GB

Max speed6400 MT/s

ECC supportNo

Storage

Max drives3

NVMe slots3

Gen4 x43

SD cardNo

Ports & Connectivity

USB4 40Gbps1

Max displays3

Network

Max Ethernet2G

2.5G ports2

vProN

Physical

Dimensions108 × 108 × 40 mm

Volume0.47L

Fan size55mm

Warranty1 yr

Power

TDP15W

Notes

Feb 1 2024: Could not find in stock so disabling overall score. Wireless charging pad on top. QC concern for m.2 cooling is insufficient for gen 4 drives.
