AceMagic

AM18 7840HS

Name: AceMagic AM18 7840HS
Brand: AceMagic

CPU r7 7840HS

GPU RDNA3 780M

Max RAM 64GB

Drives 1

From $635

Seller Amazon

The AceMagic AM18 7840HS is a mini PC powered by the AMD r7 7840HS (Zen 4 gen). It features 8 performance cores and 16 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA3 780M. Supports up to 64GB of RAM across 2 slots at 5600 MT/s. Storage capacity of up to 1 drive including 1 NVMe. Connectivity includes USB4 40Gbps. Networking features 2 Ethernet ports (up to 2.5G). Dimensions: 131 × 131 × 59mm (1.01L). Uses a Brick PSU (100W), 45W TDP.

CPU & Performance

CPUr7 7840HS

GenerationZen 4

P-Cores8

Threads16

Single-core76

Multi-core44

Socket0

GPU

GPURDNA3 780M

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

iGPU FP324300

RAM

Max RAM64GB

RAM slots2

Max speed5600 MT/s

ECC supportNo

Storage

Max drives1

NVMe slots1

Gen4 x41

SD cardNo

Ports & Connectivity

USB4 40Gbps1

Max displays3

Network

Max Ethernet2G

2.5G ports1

1G ports1

vProN

Physical

Dimensions131 × 131 × 59 mm

Volume1.01L

Fan size100mm

Warranty3 yr

Power

TDP45W

PSU typeBrick

PSU100W

Pricing

32GB / 1TB$635

Notes

Aug 6 2024: Robtech found the 100W power supply insufficient for balance and performance mode and would shut off. Changing the power profile did not provide much of a performance difference. May 28 2024: $460 to $350. May 1 2024: $540 to $460
