Asrock
Announced DeskMeet B760
GPU Desktop GPU Slot
Max RAM 128GB
Drives 4
The Asrock Announced DeskMeet B760 is a mini PC. It features a LGA1700 socket. Graphics are handled by the discrete Desktop GPU Slot. Supports up to 128GB of RAM across 4 slots at 6000 MT/s. Storage capacity of up to 4 drives including 2 NVMe, 1× 3.5" SATA and 2× 2.5" SATA. Connectivity includes HDMI 2.1. Networking features 1 Ethernet port (up to 2.5G). Dimensions: 219 × 218 × 168mm (8.02L). Uses a SFX PSU (500W).
CPU & Performance
Generation14th
SocketLGA1700
GPU
GPUDesktop GPU Slot
Discrete GPUYes
Integrated GPUYes
eGPU supportNo
RAM
Max RAM128GB
RAM slots4
Max speed6000 MT/s
ECC supportNo
Storage
Max drives4
NVMe slots2
Gen5 x41
Gen4 x41
2.5" SATA2
SD cardNo
Ports & Connectivity
HDMI 2.11
Max displays4
Network
Max Ethernet1G
2.5G ports1
vProN
Physical
Dimensions219 × 218 × 168 mm
Volume8.02L
Fan size120mm
Warranty1 yr
Power
PSU typeSFX
PSU500W
Discover More
Banana Pi
BPI-F2S FPGA 512MB
Banana Pi BPI-F2S FPGA 512MB features ARM ARM SP7021, 0.5GB RAM, offering ultra-compact 0.23L form factor.
CPU ARM ARM SP7021
Cores / Threads 4 / 4
Socket Soldered
GPU Other UNK
RAM 0.5GB
Drives 1
Ethernet 2 (1G)
Size 135×80×21mm
Vol 0.23L
Framework
