Asrock

DeskMeet B660 14900

Name: Asrock DeskMeet B660 14900
Brand: Asrock

CPU i9 14900

GPU Intel UHD 770

Max RAM 128GB

Drives 4

From $1,030

Seller Newegg

The Asrock DeskMeet B660 14900 is a mini PC powered by the Intel i9 14900 (14th gen). It features 8 performance cores and 32 threads and a LGA1700 socket. Graphics are handled by the integrated Intel Intel UHD 770. Supports up to 128GB of RAM across 4 slots at 3200 MT/s. Storage capacity of up to 4 drives including 2 NVMe, 1× 3.5" SATA and 2× 2.5" SATA. Connectivity includes HDMI 2.1. Networking features 1 Ethernet port (up to 1G). Dimensions: 219 × 218 × 168mm (8.02L). Uses a SFX PSU (500W), 65W TDP.

CPU & Performance

CPUi9 14900

Generation14th

P-Cores8

Threads32

Single-core91

Multi-core67

SocketLGA1700

GPU

GPUIntel UHD 770

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

RAM

Max RAM128GB

RAM slots4

Max speed3200 MT/s

ECC supportNo

Storage

Max drives4

NVMe slots2

Gen4 x42

2.5" SATA2

SD cardNo

Ports & Connectivity

HDMI 2.11

Max displays3

Network

Max Ethernet1G

1G ports1

vProN

Physical

Dimensions219 × 218 × 168 mm

Volume8.02L

Fan size120mm

Warranty1 yr

Power

TDP65W

PSU typeSFX

PSU500W

Notes

2.5 inch drives can be swapped for 3.5 inch drive, fits up to a 3060 Ti, there is a third sata connector for a custom third 2.5" drive mount. April 2: I made a mistake and missed a m.2 NVMe drive on the back of mobo, HDMI 2.1 requires discrete GPU to be added
