Asus

PN53 6600H

Name: Asus PN53 6600H
Brand: Asus

CPU r5 6600H

GPU RDNA2 660M

Max RAM 64GB

Drives 3

From $321

Seller Amazon

The Asus PN53 6600H is a mini PC powered by the AMD r5 6600H (Zen 3+ gen). It features 6 performance cores and 12 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA2 660M. Supports up to 64GB of RAM across 2 slots at 4800 MT/s. Storage capacity of up to 3 drives including 2 NVMe, 1× 2.5" SATA. Connectivity includes USB4 40Gbps, HDMI 2.1. Networking features 1 Ethernet port (up to 2.5G). Dimensions: 130 × 120 × 58mm (0.90L). Uses a Brick PSU (150W), 45W TDP.

CPU & Performance

CPUr5 6600H

GenerationZen 3+

P-Cores6

Threads12

Single-core63

Multi-core26

Socket0

GPU

GPURDNA2 660M

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

RAM

Max RAM64GB

RAM slots2

Max speed4800 MT/s

ECC supportNo

Storage

Max drives3

NVMe slots2

Gen4 x42

2.5" SATA1

SD cardNo

Ports & Connectivity

HDMI 2.11

USB4 40Gbps2

Max displays4

Network

Max Ethernet1G

2.5G ports1

vProN

Physical

Dimensions130 × 120 × 58 mm

Volume0.9L

Fan size80mm

Warranty3 yr

Power

TDP45W

PSU typeBrick

PSU150W

Notes

May 1 2024: $370 to $321. April 22 2024: $450 to $370. $455 to $430 April 20, HDMI 2.1 requires configurable port installed by Asus, most PN53 will be sold with a displayport 1.4 port
