Beelink

SER6 Max 6900HX

Name: Beelink SER6 Max 6900HX
Brand: Beelink

CPU r9 6900HX

GPU RDNA2 680M

Max RAM 64GB

Drives 2

From $540

Seller Aliexpress

The Beelink SER6 Max 6900HX is a mini PC powered by the AMD r9 6900HX (Zen 3+ gen). It features 8 performance cores and 16 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA2 680M. Supports up to 64GB of RAM across 2 slots at 4800 MT/s. Storage capacity of up to 2 drives including 2 NVMe. Connectivity includes USB4 40Gbps, HDMI 2.1. Networking features 1 Ethernet port (up to 2.5G). Dimensions: 126 × 113 × 49mm (0.70L). Uses a Mag PSU (100W), 65W TDP.

CPU & Performance

CPUr9 6900HX

GenerationZen 3+

P-Cores8

Threads16

Single-core66

Multi-core36

Socket0

GPU

GPURDNA2 680M

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

RAM

Max RAM64GB

RAM slots2

Max speed4800 MT/s

ECC supportNo

Storage

Max drives2

NVMe slots2

Gen4 x42

SD cardNo

Ports & Connectivity

HDMI 2.11

USB4 40Gbps2

Max displays4

Network

Max Ethernet1G

2.5G ports1

vProN

Physical

Dimensions126 × 113 × 49 mm

Volume0.7L

Fan size80mm

Warranty1.5 yr

Power

TDP65W

PSU typeMag

PSU100W

Pricing

32GB / 1TB$540

Notes

Oct 5: USB C PD 3.0 charging does not always work. Sep 1: second NVMe port can be adapted to sata for a 2.5" drive. TDP limit increased from SER6 Pro 54W to SER6 Max 65W
