CWWK/Topton
1220P 2SFP 4x2.5G
CPU i3 1220P
GPU Iris Xe 64EU
Max RAM 64GB
Drives 4
Seller CWWK/Topton
The CWWK/Topton 1220P 2SFP 4x2.5G is a mini PC powered by the Intel i3 1220P (12th gen). It features 2 performance cores and 12 threads and a soldered CPU. Graphics are handled by the integrated Intel Iris Xe 64EU. Supports up to 64GB of RAM across 2 slots at 4800 MT/s. Storage capacity of up to 4 drives including 1 NVMe, 2× 2.5" SATA. Networking features 6 Ethernet ports (up to 10G). Dimensions: 155 × 132 × 60mm (1.23L).
CPU & Performance
CPUi3 1220P
Generation12th
P-Cores2
Threads12
Single-core67
Multi-core21
Socket0
GPU
GPUIris Xe 64EU
Discrete GPUNo
Integrated GPUYes
eGPU supportNo
RAM
Max RAM64GB
RAM slots2
Max speed4800 MT/s
ECC supportNo
Storage
Max drives4
NVMe slots1
Gen4 x41
2.5" SATA2
SD cardYes
Ports & Connectivity
Max displays4
Network
Max Ethernet6G
10G ports2
2.5G ports4
Physical
Dimensions155 × 132 × 60 mm
Volume1.23L
Fan size80mm
Power
Discover More
ZOTAC
ZBOX-CI662NANO
ZOTAC ZBOX-CI662NANO features Intel i7 10510U, 32GB RAM.
CPU Intel i7 10510U
Cores / Threads 4 / 8
Socket Soldered
GPU Intel Intel UHD 620
RAM 32GB / 2slots
Speed 2666 MT/s
Drives 3
SATA 1×2.5"
Ethernet 2 (1G)
PSU Brick
Size 204×129×68mm
Vol 1.79L
FIREBAT
