GMKtec

NucBox K2

Name: GMKtec NucBox K2
Brand: GMKtec

CPU r7 7735HS/6800H

GPU RDNA2 680M

Max RAM 64GB

Drives 1

From $470

Seller Amazon

The GMKtec NucBox K2 is a mini PC powered by the AMD r7 7735HS/6800H (Zen 3+ gen). It features 8 performance cores and 16 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA2 680M. Supports up to 64GB of RAM across 2 slots at 4800 MT/s. Storage capacity of up to 1 drive including 1 NVMe. Connectivity includes USB4 40Gbps. Networking features 1 Ethernet port (up to 2.5G). Dimensions: 122 × 112 × 43mm (0.59L). Uses a Brick PSU (120W), 35W TDP.

CPU & Performance

CPUr7 7735HS/6800H

GenerationZen 3+

P-Cores8

Threads16

Single-core65

Multi-core36

Socket0

GPU

GPURDNA2 680M

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

RAM

Max RAM64GB

RAM slots2

Max speed4800 MT/s

ECC supportNo

Storage

Max drives1

NVMe slots1

Gen3 x41

SD cardNo

Ports & Connectivity

USB4 40Gbps1

Max displays3

Network

Max Ethernet1G

2.5G ports1

vProN

Physical

Dimensions122 × 112 × 43 mm

Volume0.59L

Fan size80mm

Warranty1 yr

Power

TDP35W

PSU typeBrick

PSU120W

Pricing

32GB / 1TB$470

Notes

Oct 22: $450 to $270. Sep 7: Multiple reports of thermal throttling. It is recommended to add a second fan. July 29: Bios default 35W TDP instead of 45W to reduce thermal throttling
