Geekom
AE8 Max 8745HS
CPU r7 8845HS/7840HS
GPU RDNA3 780M
Max RAM 64GB
Drives 3
From $512
Seller Amazon
The Geekom AE8 Max 8745HS is a mini PC powered by the AMD r7 8845HS/7840HS (Zen 4 gen). It features 8 performance cores and 16 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA3 780M. Supports up to 64GB of RAM across 2 slots at 5600 MT/s. Storage capacity of up to 3 drives including 1 NVMe. Connectivity includes USB4 40Gbps. Networking features 2 Ethernet ports (up to 2.5G). Dimensions: 137 × 132 × 58mm (1.05L). Uses a GaN/Brick PSU (120W), 45W TDP.
CPU & Performance
CPUr7 8845HS/7840HS
GenerationZen 4
P-Cores8
Threads16
Single-core76
Multi-core44
Socket0
GPU
GPURDNA3 780M
Discrete GPUNo
Integrated GPUYes
eGPU supportNo
RAM
Max RAM64GB
RAM slots2
Max speed5600 MT/s
ECC supportNo
Storage
Max drives3
NVMe slots1
Gen4 x41
SD cardYes
Ports & Connectivity
USB4 40Gbps2
Max displays4
Network
Max Ethernet2G
2.5G ports2
Physical
Dimensions137 × 132 × 58 mm
Volume1.05L
Fan size80mm
Warranty3 yr
Power
TDP45W
PSU typeGaN/Brick
PSU120W
Pricing
32GB / 1TB$512
Notes
DDR5 thermal throttles
