Mini PC DataBase

MSI Cubi NUC 1MG (Silver) 100U

MSI

Cubi NUC 1MG (Silver) 100U

CPU i3 100U

GPU Iris Xe 64EU

Max RAM 64GB

Drives 4

Seller Newegg

The MSI Cubi NUC 1MG (Silver) 100U is a mini PC powered by the Intel i3 100U (13th gen). It features 2 performance cores and 8 threads and a soldered CPU. Graphics are handled by the integrated Intel Iris Xe 64EU. Supports up to 64GB of RAM across 2 slots at 5200 MT/s. Storage capacity of up to 4 drives including 2 NVMe, 1× 2.5" SATA. Connectivity includes USB4 40Gbps. Networking features 2 Ethernet ports (up to 2.5G). Dimensions: 136 × 133 × 50mm (0.90L). Uses a Brick PSU (120W).

CPU & Performance

CPUi3 100U

Generation13th

P-Cores2

Threads8

Single-core75

Multi-core21

Socket0

GPU

GPUIris Xe 64EU

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

RAM

Max RAM64GB

RAM slots2

Max speed5200 MT/s

ECC supportNo

Storage

Max drives4

NVMe slots2

Gen4 x41

Gen3 x41

2.5" SATA1

SD cardYes

Ports & Connectivity

USB4 40Gbps1.25

Max displays4

Network

Max Ethernet2G

2.5G ports2

vProN

Physical

Dimensions136 × 133 × 50 mm

Volume0.9L

Fan size80mm

Warranty3 yr

Power

PSU typeBrick

PSU120W

Notes

Supports HDMI CEC power on with compatible MSI monitors, video output is limited to 4k 60hz and not 8k 60hz

Discover More

CHATREEY G2/F10 12900H 4060

G2/F10 12900H 4060

CHATREEY G2/F10 12900H 4060 features Intel i9 12900H with NVIDIA Mobile 4060 discrete GPU.

CPU Intel i9 12900H

Cores / Threads 6 / 20

Socket Soldered

GPU NVIDIA Mobile 4060

RAM 64GB / 2slots

Speed 3200 MT/s

Drives 3 (2 NVMe)

Ethernet 1 (2.5G)

Size 310×250×55mm

Topton X8

X8

Topton X8 features Intel i7 10510U, 64GB RAM, offering 8× 2.5G Ethernet.

CPU Intel i7 10510U

Cores / Threads 4 / 8

Socket Soldered

GPU Intel Intel UHD 620

RAM 64GB / 2slots

Speed 2666 MT/s

Drives 7 (1 NVMe)

Ethernet 8 (2.5G)

Size 150×132×60mm

ZXiPC ZNR 5800U
