Morefine
S500+ 7840U
CPU r7 7840U
GPU RDNA3 780M
Max RAM 16GB
Drives 2
From $440
Seller Morefine
The Morefine S500+ 7840U is a mini PC powered by the AMD r7 7840U (Zen 4 gen). It features 8 performance cores and 16 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA3 780M. Supports up to 16GB of RAM at 6400 MT/s. Storage capacity of up to 2 drives including 2 NVMe. Connectivity includes USB4 40Gbps, HDMI 2.1. Networking features 2 Ethernet ports (up to 2.5G). Dimensions: 149 × 145 × 40mm (0.86L). Uses a Brick PSU, 15W TDP.
CPU & Performance
CPUr7 7840U
GenerationZen 4
P-Cores8
Threads16
Single-core71
Multi-core37
Socket0
GPU
GPURDNA3 780M
Discrete GPUNo
Integrated GPUYes
eGPU supportNo
iGPU FP324300
RAM
Max RAM16GB
Max speed6400 MT/s
ECC supportNo
Storage
Max drives2
NVMe slots2
Gen4 x42
SD cardNo
Ports & Connectivity
HDMI 2.11
USB4 40Gbps0.5
Max displays3
Network
Max Ethernet2G
2.5G ports2
vProN
Physical
Dimensions149 × 145 × 40 mm
Volume0.86L
Fan size80mm
Warranty1 yr
Power
TDP15W
PSU typeBrick
Pricing
16GB / 512GB$440
Notes
Feb 20 2024: USB4 might be 20gbps because 8k 30hz limit
Discover More
AYANEO
