Mini PC DataBase

Asrock 4x4 box 7535U/D5

Asrock

4x4 box 7535U/D5

CPU r5 7535U/6650U

GPU RDNA2 660M

Max RAM 64GB

Drives 2

From $545

Seller Newegg

The Asrock 4x4 box 7535U/D5 is a mini PC powered by the AMD r5 7535U/6650U (Zen 3+ gen). It features 6 performance cores and 12 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA2 660M. Supports up to 64GB of RAM across 2 slots at 4800 MT/s. Storage capacity of up to 2 drives including 1 NVMe, 1× 2.5" SATA. Connectivity includes USB4 40Gbps, HDMI 2.1. Networking features 2 Ethernet ports (up to 2.5G). Dimensions: 118 × 110 × 48mm (0.62L). Uses a Brick PSU (90W), 15W TDP.

CPU & Performance

CPUr5 7535U/6650U

GenerationZen 3+

P-Cores6

Threads12

Single-core65

Multi-core26

Socket0

GPU

GPURDNA2 660M

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

RAM

Max RAM64GB

RAM slots2

Max speed4800 MT/s

ECC supportNo

Storage

Max drives2

NVMe slots1

Gen4 x41

2.5" SATA1

SD cardNo

Ports & Connectivity

HDMI 2.11

USB4 40Gbps1

Max displays4

Network

Max Ethernet2G

2.5G ports1

1G ports1

vProN

Physical

Dimensions118 × 110 × 48 mm

Volume0.62L

Fan size80mm

Warranty1 yr

Power

TDP15W

PSU typeBrick

PSU90W

Notes

Feb 6 2024: $480 to $546. Added April 20

Discover More

Intel NUC6i5SYH

NUC6i5SYH

Intel NUC6i5SYH features Intel i5 6260U, 32GB RAM, offering compact 0.66L design.

CPU Intel i5 6260U

Cores / Threads 2 / 4

Socket Soldered

GPU Intel Iris Graphics 540

RAM 32GB / 2slots

Speed 2133 MT/s

Drives 3 (1 NVMe)

Ethernet 1 (1G)

Size 115×112×51mm

Apple Mac mini M4 Pro 12-Core 24GB 2TB

Mac mini M4 Pro 12-Core 24GB 2TB

Apple Mac mini M4 Pro 12-Core 24GB 2TB features Apple ARM M4 Pro 12 Core, 24GB RAM, offering Thunderbolt 5 and compact 0.81L design.

CPU Apple ARM M4 Pro 12 Core

Cores / Threads 8 / 12

Socket Soldered

GPU Apple M4 Pro 16-core

Speed 7500 MT/s

Ethernet 1 (1G)

Size 127×127×50mm

GPD P2 Max 8100Y
