Mini PC DataBase

Asrock 4x4 box 7735U/D5

Asrock

4x4 box 7735U/D5

CPU r7 7735U/6850U

GPU RDNA2 680M

Max RAM 64GB

Drives 2

From $630

Seller Newegg

The Asrock 4x4 box 7735U/D5 is a mini PC powered by the AMD r7 7735U/6850U (Zen 3+ gen). It features 8 performance cores and 16 threads and a soldered CPU. Graphics are handled by the integrated AMD RDNA2 680M. Supports up to 64GB of RAM across 2 slots at 4800 MT/s. Storage capacity of up to 2 drives including 1 NVMe, 1× 2.5" SATA. Connectivity includes USB4 40Gbps, HDMI 2.1. Networking features 2 Ethernet ports (up to 2.5G). Dimensions: 118 × 110 × 48mm (0.62L). Uses a Brick PSU (90W), 15W TDP.

CPU & Performance

CPUr7 7735U/6850U

GenerationZen 3+

P-Cores8

Threads16

Single-core65

Multi-core31

Socket0

GPU

GPURDNA2 680M

Discrete GPUNo

Integrated GPUYes

eGPU supportNo

RAM

Max RAM64GB

RAM slots2

Max speed4800 MT/s

ECC supportNo

Storage

Max drives2

NVMe slots1

Gen4 x41

2.5" SATA1

SD cardNo

Ports & Connectivity

HDMI 2.11

USB4 40Gbps1

Max displays4

Network

Max Ethernet2G

2.5G ports1

1G ports1

vProN

Physical

Dimensions118 × 110 × 48 mm

Volume0.62L

Fan size80mm

Warranty1 yr

Power

TDP15W

PSU typeBrick

PSU90W

Notes

Added April 20

Discover More

Morefine S700 155H 4080M

S700 155H 4080M

Morefine S700 155H 4080M features Intel U7 155H with NVIDIA Mobile 4080 discrete GPU, offering 2× 2.5G Ethernet and USB4.

CPU Intel U7 155H

Cores / Threads 6 / 22

Socket Soldered

GPU NVIDIA Mobile 4080

RAM 96GB / 2slots

Speed 5600 MT/s

Drives 3 (2 NVMe)

Ethernet 2 (2.5G)

Size 130×129×54mm

Asus NUC 13 Rugged Tall

NUC 13 Rugged Tall

Asus NUC 13 Rugged Tall features Intel Atom X7211E, 16GB RAM, offering 2× 2.5G Ethernet and compact 0.68L design.

CPU Intel Atom X7211E

Cores / Threads – / 2

Socket Soldered

GPU Intel Iris Xe 16EU

RAM 16GB / 1slot

Speed 4800 MT/s

Drives 2 (2 NVMe)

Ethernet 2 (2.5G)

Size 174×108×36mm

Gigabyte GB-BRi3H-1315

GB-BRi3H-1315

Gigabyte GB-BRi3H-1315 features Intel i3 1315U, 64GB RAM, offering compact 0.74L design.

CPU Intel i3 1315U

Cores / Threads 2 / 8

Socket Soldered

GPU Intel Iris Xe 64EU

RAM 64GB / 2slots

Speed 3200 MT/s

Drives 2 (1 NVMe)

Ethernet 1 (2.5G)

Size 124×120×49.7mm
